All-steel laboratory bench

★ Height: 800 or 850
★ Specification: 450, 500, 900, 1000*1000 (corner cabinet)
★ Style: double door, single door single drawer, double door double drawer, three drawer cabinet, corner cabinet
★ Color: gray, lake blue, gemstone blue, Indonesia white
★ Other: cabinet galvanized plate thickness of 1mm, pull style is divided into open pull and dark pull, the cabinet door connection for hinges or hinges
★ Dimension of experiment side table: L*750*800mm
★ Laboratory center table size: L*1500*800mm

Product Details

Cabinet material: the whole cabinet is made of 1.0mm thick, galvanized sheet production, cabinet surface epoxy resin powder electrostatic spraying, high temperature curing, high adhesion, scratch resistance, acid and alkali resistance, beautiful and durable;

Slide: 16 inch DTC special slide, mute and smooth;

Hinge: stainless steel hinge, 180 degrees open;

Adjustable feet: φ8mm diameter, landing part of the hexagonal nylon, total height of 25mm, adjustable height of 15mm;

Handle: stainless steel U-shaped handle;

Plate discharging: using 2000W CNC fiber laser cutting machine imported from Germany, high speed, fast discharging, small tolerance;

Bending: fully automatic CNC bending, high operational precision, less error;

Welding: full welding;

Cabinet structure: each unit can be disassembled structure, small packaging, easy to carry before installation, small size is not easy to touch the aisles and stairs of the laboratory, easy to go upstairs, move quickly;

Assembly: more specifications, flexible combination, according to the size of the room, can be arbitrarily combined into the required laboratory table (side table or central table), can also be equipped with optional hanging cabinets, cabinets from the 300 host cabinet to 1000 double-door double drawer cabinets, every 25mm there is a unit of cabinets, but also with drawers to sit with the keyboard shelf sitting position and empty sitting position;

Color: Cabinet is mainstream fashionable grey, skirting color is dark grey similar to the room's skirting;

Countertop: 12.7mm solid physicochemical board countertop or marble countertop. Resistant to strong acid and alkali corrosion resistance, high temperature resistance. The outer edge of the hanging edge is thickened to 25.4mm thick, two-way curved chamfering, excellent appearance and feel.


Product Characteristics

All-steel laboratory bench

All-steel laboratory bench

All-steel laboratory bench
